- Year
- 2019
- Parts listed
- 15
- Sheet
- SPK-3505
Click a part to see its size and where to buy it.
Full parts list
Frame and standards
- 01Bottom bracketSHIMANO "BB-UN100"
- 02ForkRST "Capa T"RST "Capa T", 80 mmSigma Sports bike-components Bike24
- 03SeatpostØ31.6 mmØ31.6mm · CONWAY Patent, Ø 31,6 mmSigma Sports bike-components Bike24
Drivetrain
- 04CassetteSHIMANO TZ500SHIMANO TZ500, 14-34 Z.Sigma Sports bike-components Bike24
- 05Rear derailleurShimano RD-TX800SHIMANO RD-TX800, 7-fachSigma Sports bike-components Bike24
- 06Front derailleurShimano FD-TY700Sigma Sports bike-components Bike24
- 07CranksetShimano FC-TY301SHIMANO FC-TY301, 24/34/42 Z., 175 mmSigma Sports bike-components Bike24
- 08ShiftersShimano ST-EF41Sigma Sports bike-components Bike24
Brakes
- 09BrakesV-BrakeSigma Sports bike-components Bike24
Wheels and tyres
- 10TyresIMPAC SmartpacIMPAC Smartpac, 54-622, ReflexSigma Sports bike-components Bike24
- 11Wheels / rimsCONWAY Hohlkammer J 20Sigma Sports bike-components Bike24
- 12HubsSHIMANO Nabendynamo DHC3000SHIMANO Nabendynamo DHC3000, QRSigma Sports bike-components Bike24
Cockpit
- 13HandlebarCONWAY RiserCONWAY Riser, Ø 31,8, 720 mm
- 14Grips / bar tapeCONWAY Sport
- 15SaddleCONWAY 3378 lightSigma Sports bike-components Bike24
Not listed: Frame, Headset, Seat clamp, Derailleur hanger.
Parts of the original build, with their exact model: check the bike in case it was modified.Source ↗
