- Year
- 2018
- Parts listed
- 15
- Sheet
- SPK-4101
Click a part to see its size and where to buy it.
Full parts list
Frame and standards
- 01Bottom bracketSHIMANO "BB-UN100"
- 02ForkSUNTOUR "XCT"SUNTOUR "XCT", 100mm, einstellbar
- 03SeatpostCONWAY Patent
Drivetrain
- 04CassetteSHIMANO HG31SHIMANO HG31, 11-34 Z.Sigma Sports bike-components Bike24
- 05Rear derailleurShimano RD-TX800Sigma Sports bike-components Bike24
- 06Front derailleurShimano FD-TY700Sigma Sports bike-components Bike24
- 07CranksetShimano FC-TY301SHIMANO FC-TY301, 24/34/42 Z., 170 mmSigma Sports bike-components Bike24
- 08ShiftersShimano SL-M310SHIMANO Altus SL-M310Sigma Sports bike-components Bike24
Brakes
- 09BrakesShimano BR-M315SHIMANO BR-M315, 160 mmSigma Sports bike-components Bike24
Wheels and tyres
- 10TyresIMPAC RidgepacIMPAC Ridgepac, 54-584Sigma Sports bike-components Bike24
- 11Wheels / rimsCONWAY Hohlkammer X-11CONWAY Hohlkammer X-11, DiscSigma Sports bike-components Bike24
- 12HubsShimano HB-TX505SHIMANO HB-TX505 QRSigma Sports bike-components Bike24
Cockpit
- 13HandlebarCONWAY RiserCONWAY Riser, Ø 31,8, 720 mmSigma Sports bike-components Bike24
- 14Grips / bar tapeCONWAY SportSigma Sports bike-components Bike24
- 15SaddleSELLE ROYAL Mach2Sigma Sports bike-components Bike24
Not listed: Frame, Headset, Seat clamp, Derailleur hanger.
Parts of the original build, with their exact model: check the bike in case it was modified.Source ↗
