- Anno
- 2024
- Ricambi censiti
- 14
- Scheda
- SPK-1227
Clicca su un ricambio per vedere la misura e dove comprarlo.
Distinta completa
Telaio e standard
- 01TelaioOrbea OMR Carbon
- 02Movimento centraleBSA 73 mm (filettato)BSA 73mm Threaded · Filetage BSA — 73mmAlltricks bike-components Bike24
- 03Serie sterzoZS44 | ZS56Acros Integrated · Sup. ZS44 — Inf. ZS56Alltricks bike-components Bike24
- 04ForcellaFourche 170mmdébattement 170mm · axe-té max 594mm (587.7mm recommended). · déport 44mm
- 05Ammortizzatore posteriore230 × 62 mmMetric. 230x62 · débattement AR 29" = 167mm · sag 28%-33%Alltricks bike-components Bike24
- 06Cuscinetti dei pivot del telaio6803 (17x26x5), 6903 (17x30x7), 20307 (20x30x7), 6802 (15x24x5) ×2, 6800 (10x19x5), 6804 (20x32x7)6803 17x26x5 mm ×1 · 6903 17x30x7 mm ×1 · 20307 20x30x7 mm ×1 · 6802 15x24x5 mm ×2 · 6800 10x19x5 mm · 6804 20x32x7 mm · Kits Orbea : XA19, XA16, XA29, XA24, XA25Alltricks bike-components Bike24
- 07Boccole e viteria ammortizzatore8x21.84mm / 8x16.45mmFront triangle 8x21.84mm · Shock yoke 8x16.45mm
- 08ReggisellaØ34,9 mmOrbea OC4 Dropper · Ø34.9mmAlltricks bike-components Bike24
- 09Collarino reggisellaØ35,0 mmØ35mmAlltricks bike-components Bike24
- 10Forcellino cambioSRAM UDH (forcellino universale)Patte de dérailleur Orbea X004 (SRAM UDH) · Universal Derailleur HangerAlltricks bike-components Bike24
- 11Perno passante posteriore12 × 148 mmBoost 12x148 · axe 12x187mm · pas 1.0mmAlltricks bike-components Bike24
- 12Freni (attacco e dischi)POST MOUNT · disques AV max 220 mm, AR min 180 mm, AR max 223 mmAR : POST MOUNT
- 13Compatibilità trasmissioneLigne de chaîne Boost. 52mm. Compatible with 55mm chainline cranksetsligne de chaîne Boost. 52mm. Compatible with 55mm chainline cranksets · plateau max 32T. With 52mm chainline cranksets (Orbea assemblies) 36T. With 55mm chainline cranksets · dérailleur avant : No. Only 1X · ISCG05 : Yes. ICGS05 Orbea assemblies: E-Thirteen Vario Ultracompact 30-36T 52mm Chainline · SRAM T-Type : Yes · 11S and 12S (1X). MTB Boost. Chainline 52mm y 55mm
- 14Ruote e passaggio pneumatici29" or Mullet (29"Front/27.5" Rear) Requires to swap the shock yoke · pneu max 2.5" (with 8mm clearance between frame and tyre)AV : Depends on fork
Componenti del montaggio originale, con il modello esatto: controlla la bici nel caso sia stata modificata.Fonte ↗
