Trek 140 (Stepover) 2026

altro

Clicca su un ricambio per vedere la misura e dove comprarlo.

Distinta completa

01TelaioFrameFrame. Alpha Smooth Aluminum, internal cable routing, post-mount disc, replaceable dropouts, belt split, ringlock mount
02Serie sterzoIntegratedFSA IS-2/42E/ACB, E2, Integrated, 36 inner/45 outer Chamfer, Industry standard 1-1/8'' to 1.5'' tapered headset with 1.5'' crown race and 41mm OD top bearing cover, black
03ForcellaSuntour NCX 32 Suspension forkSuntour NCX 32 Suspension fork, 29'', Unthreaded steerer tube, Post Mount, Matte Black
04ReggisellaØ31,6 mmØ31.6mm · Bontrager Approved Seatpost, 31.6x330mm, 12mm Offset, BlackAlltricks bike-components Bike24
05Collarino reggisellaØ36,4 mmØ36.4mm · Bontrager Seatpost Collar 36.4 BlackAlltricks bike-components Bike24

06CatenaShimano SLX Chain. Item Number: M7100Shimano SLX Chain. Item Number: M7100, 12-Speed, With Quick Link (Visit si.shimano.com for compatibility, manuals and exploded views)Alltricks bike-components Bike24
07GuarnituraCrankset Prowheel TK01 42TCrankset Prowheel TK01 42T, 175mm, 10-11 Speed, Aluminum, Anodized Black, for 136mm Axle, 49.6mm chainline, With Narrow/Wide Teeth 42T Black. With ChainguardAlltricks bike-components Bike24

08FreniShimano BR-RX410Shimano GRX Rear Disc brake set. BL-RX610-R, BR-RX410-FR For 160mm rotor. With Resin brake pad. 1700mm brake hose (SM-BH90). BlackAlltricks bike-components Bike24
09Dischi frenoShimano SM-RT30Shimano Rotor. Item Number: SM-RT30-M, 180mm, Center Lock, For Resin Pad only. (Visit si.shimano.com for compatibility, manuals and exploded views)Alltricks bike-components Bike24

10Ruote / cerchiBontrager Kovee RimBontrager Kovee Rim, 27.5'', double-wall, Tubeless Ready, 32-hole, 23mm width, for Disc brakes only, Presta valve, 25mm inner hook bead, non eyeleted, BlackAlltricks bike-components Bike24

11ManubrioBontrager Elite Alloy Gravel IsoZone HandlebarBontrager Elite Alloy Gravel IsoZone Handlebar, 44cm, With Di2 Routing. IsoZone Pads are not includedAlltricks bike-components Bike24
12Attacco manubrioBontrager Stem EliteBontrager Stem Elite, 80mm 7 degree, 31.8mm, BlackAlltricks bike-components Bike24
13SellaBrooksBrooks, Cambium, C17, 165mm Wide, BlackAlltricks bike-components Bike24
14PedaliPédale VP VPE-536Pédale VP VPE-536, noirAlltricks bike-components Bike24

Non censito: Movimento centrale, Forcellino cambio.

Componenti del montaggio originale, con il modello esatto: controlla la bici nel caso sia stata modificata.Fonte ↗

Manuali e schemi disponibili sulla pagina del produttore.
